1. School of Resource Environment and Safety Engineering, Hunan University of Science and Technology, Xiangtan 411201,China 2. School of Geomatics, Anhui University of Science and Technology, Huainan 232001, China 3. Institute of International Rivers and Eco-Security, Yunnan University, Kunming 650500, China 4. State Key Laboratory of Cryospheric Science, Northwest Institute of Eco-Environment and Resources,Chinese Academy of Sciences, Lanzhou 730000, China
为了评估木孜塔格峰冰川在全球气候变暖背景下的变化,利用历史地形图数据、Landsat遥感影像、数字高程模型(digital elevation model , DEM)数据及TerraSAR-X/TanDEM-X数据,基于合成孔径雷达干涉测量(interferometry synthetic aperture Radar,InSAR)和大地测量法对木孜塔格峰地区1972—2011年间的冰川面积变化和物质平衡进行了详细研究。结果表明: 1972—2011年间木孜塔格峰地区冰川面积年均缩减率为0.02±0.06%,其中47条冰川表现为退缩,2条冰川表现为前进; 木孜塔格峰地区冰川物质呈现微弱的负平衡(-0.06±0.01 m w.e./a)趋势,其中1999年以前为-0.11±0.02 m w.e./a,主要受气温升高所影响,1999年后几乎接近于平衡状态(0.02±0.04 m w.e./a),降水的增加弥补了气温升高造成的物质亏损; 木孜塔格峰地区冰川前进不同于正常前进冰川,其前进原因可能是冰川内部消融引起的液态水润滑作用导致上游物质向下转移; 在当前气候背景下,该区域大部分冰川表现为退缩,2条冰川有前进现象,1条冰川有过跃动(崩塌)现象,总体上该区域冰川呈现微弱的物质负平衡。
In order to further understand the glacier change in Ulugh Muztagh under the background of climate change, historical topographic map data, Landsat TM, SRTM DEM and TerraSAR-X/TanDEM-X data with bi-static mode were employed to obtain the detail change of the glacier area and mass balance between 1972 and 2011 around Muztagh peak. The results indicated that reduction rate of annual glacier area was 0.02±0.06% between 1972 and 2011. Among all glaciers, 47 glaciers showed retreat while 2 glaciers advanced for some distance. And the mass change showed a slight negative balance (-0.06±0.01 m w.e./a) for the whole region. From 1972 to 1999, the mass balance was -0.11±0.02 m w.e./a, caused probably by the temperature rising; From 1999 to 2011, the mass change was close to balance (0.02±0.04 m w.e./a), caused by the precipitation increasing. Glacier advance in Muztagh was different from that of normal advanced glacier. For this kind of Polar type glaciers, it was probably caused by the inner melting or liquid water occurrence due to more precipitation that made some glaciers moving forward or surging. In the background of the current climate, most glaciers showed retreat but two glaciers advanced and one glacier surged (avalanche); overall, the glaciers in the region showed slightly negative mass balance.
Jacob T, Wahr J, Pfeffer W T , et al. Recent contributions of glaciers and ice caps to sea level rise[J]. Nature, 2012,482(7386):514-518.
[2]
Gardner A S, Mohold G, Cogley J G , et al. A reconciled estimate of glacier contributions to sea levelrise:2003 to 2009[J]. Science, 2013,340(6134):852-857.
[3]
Immerzeel W W, van Beek L P H, Bierkens M F P . Climate change will affect the Asian water towers[J]. Science, 2010,328(5984):1382-1385.
[4]
Marzeion B, Kaser G, Maussion F , et al. Limited influence of climate change mitigation on short-term glacier mass loss[J]. Nature Climate Change, 2018,8(4):305-308.
[5]
Lambrecht A, Mayer C, Wendt A , et al. Elevation change of Fedchenko Glacier,Pamir Mountains,from GNSS field measurements and TanDEM-X elevation models,with a focus on the upper glacier[J]. Journal of Glaciology, 2018,64(246):637-648.
[6]
Li G, Lin H, Ye Q H . Heterogeneous decadal glacier downwasting at the Mt.Everest (Qomolangma) from 2000 to 2012 based on multi-baseline bistatic SAR interferometry[J]. Remote Sensing of Environment, 2018,206:336-349.
[7]
Wu K P, Liu S Y, Jiang Z L , et al. Recent glacier mass balance and area changes in the Kangri Karpo Mountains from DEMs and glacier inventories[J]. The Cryosphere, 2018,12(1):103-121.
[8]
Zhang Z, Liu S Y, Zhang Y , et al. Glacier variations at Aru Co in western Tibet from 1971 to 2016 derived from remote-sensing data[J]. Journal of Glaciology, 2018,64(245):397-406.
[9]
Rankl M, Braun M . Glacier elevation and mass changes over the central Karakoram region estimated from TanDEM-X and SRTM/X-SAR digital elevation models[J]. Annals of Glaciology, 2016,51(71):273-281.
[10]
Neckel N, Braun A, Kropáček J ,et al.Recent mass balance of the Purogangri ice cap,central Tibetan Plateau,by means of differential X-band SAR interferometry[J].The Cryosphere , 7(5):1623-1633.
[11]
Zhang Q B, Zhang G S . Glacier elevation changes in the western Nyainqentanglha Range of the Tibetan Plateau as observed by TerraSAR-X/TanDEM-X images[J]. Remote Sensing Letters, 2017,8(12):1143-1152.
[12]
Lin H, Li G, Cuo L , et al. A decreasing glacier mass balance gradient from the edge of the upper Tarim Basin to the Karakoram during 2000—2014[J]. Scientific Reports, 2017,7:6712.
[13]
Wei J F, Liu S Y, Guo W Q , et al. Surface-area changes of glaciers in the Tibetan Plateau interior area since the 1970s using recent Landsat images and historical maps[J]. Annals of Glaciology, 2014,55(66):213-222.
[14]
Ye Q H, Zong J B, Tian L D , et al. Glacier changes on the Tibetan Plateau derived from Landsat imagery:mid-1970s—2000-13[J]. Journal of Glaciology, 2017,63(238):273-287.
[15]
Brun F, Berthier E, Wagnon P , et al. A spatially resolved estimate of high mountain Asia glacier mass balances,2000—2016[J]. Nature Geoscience, 2017,10(9):668-673.
Guo W Q, Liu S Y, Xu J L , et al. Monitoring recent surging of the Yulinchuan glacier on north slopes of Muztag range by remote sencing[J]. Journal of Glaciology and Geocryology, 2012,34(4):765-774.
Liu S Y, Yao X J, Guo W Q , et al. The contemporary glaciers in China based on the second chinese glacier inventory[J]. Acta Geographica Sinica, 2015,70(1):3-16.
Chen Y N, Wang Y S, Wang Z C , et al. Distribution,quantity and types of modern glaciers in the Muztag peak area,eastern Kunlun[J]. Arid Zone Research, 1985,2(4):56-61.
Liu S Y, Yao X J, Guo W Q , et al. The contemporary glaciers in China based on the Second Chinese Glacier Inventory[J]. ActaGeographica Sinica, 2015,70(1):3-16.
GB/T 1234. 1—2008 Compilation specification for nation fundamental scale maps-Part1:Compilation specifications for 1:25 000 1:50 000 1:100 000 topographic maps[S].
[21]
Kolecka N, Kozak J . Assessment of the accuracy of SRTM C- and X-band high mountain elevation data:A case study of the Polish Tatra Mountains[J]. Pure and Applied Geophysics, 2014,171(6):897-912.
Jiang Z L, Liu S Y, Guo W Q , et al. Recent surface elevation changes of three representative glaciers in Ányêmaqên Mountains,source region of Yellow River[J]. Journal of Glaciology and Geocryology, 2018,40(2):231-237.
[23]
Nuth C, Kääb A . Co-registration and bias corrections of satellite elevation data sets for quantifying glacierthickness change[J]. The Cryosphere, 2011,5(1):271-290.
[24]
Gardelle J, Berthier E, Arnaud Y . Impact of resolution and Radar penetration on glacier elevation changescomputed from DEM differencing[J]. Journal of Glaciology, 2012,58(208):419-422.
[25]
Bolch T, Pieczonka T, Benn D I . Multi-decadal mass loss of glaciers in the Everest area (Nepal Himalaya) derivedfrom stereo imagery[J]. The Cryosphere, 2011,5(2):349-358.
[26]
Huss M . Density assumptions for converting geodetic glacier volume change to mass change[J]. The Cryosphere, 2013,7(3):877-887.
Wang N L, Xu B Q, Pu J C , et al. Discovery of the water-rich ice layers in glaciers on the Tibetan Plateau and its environmental significances[J]. Journal of Glaciology and Geocryology, 2013,35(6):1371-1381.
Hu F S, Yang T B, Ji Q , et al. Relationship between the glacier and climate change in the Altun Mountain in recent four decades[J]. Arid Land Geography, 2017,40(3):581-588.
Wang Y, Wu L Z, Xu J L , et al. Variation and uncertainty analysis of the glcier in the past 50 years in Geladandong of Tibetan Plateau[J]. Journal of Glaciology and Geocryology, 2013,35(2):255-262.
La B, Ge S Z M, La B Z M ,et al.Variation and reasons of the coverage of Puruogangri Glacier and its surrounding lakes during 1992—2014[J]. Arid Land Geography, 2016,39(4):770-776.
[31]
Bao W J, Liu S Y, Wei J F , et al. Glacier changes during the past 40 years in the West Kunlun Shan[J]. Journal of Mountain Science, 2015,12(2):344-357.
Zhang Z, Liu S Y . Area changes and mass balance of glaciers in KangzhagRi of the Tibetan Plateau from 1970 to 2016 as derived from remote sensing data[J]. Journal of Geo-Information Science, 2018,20(9):1338-1349.
[33]
Zhou Y S, Li Z W, Li J , et al. Glacier mass balance in the Qinghai-Tibet Plateau and its surroundings from the mid-1970s to 2000 based on Hexagon KH-9 and SRTM DEMs[J]. Remote Sensing of Environment, 2018,210:96-112.
[34]
Neckel N, Kropáček J, Bolch T , et al. Glacier mass changes on the Tibetan Plateau 2003—2009 derived from ICESat laser altimetry measurements[J]. Environmental Research Letters, 2014,9(9):468-475.
[35]
Yao T D, Thompson L, Yang W , et al. Different glacier status with atmospheric circulations in Tibetan Plateau and surroundings[J]. Nature Climate Change, 2012,2(9):663-667.
[36]
Chen, A A, Wang N L, Li Z ,et al.Region-wide glacier mass budgets for the Tanggula Mountains between 1969 and 2015 derived from remote sensing data[J]. Arctic Antarctic and Alpine Research, 2017,49(4):551-568.
