Spatio-temporal change characteristics of rubber forest phenology in Hainan Island during 2001—2015
HU Yingying1,2(), DAI Shengpei1,2(), LUO Hongxia1,2, LI Hailiang1,2, LI Maofen1,2, ZHENG Qian1,2, YU Xuan1,2, LI Ning3
1. Institute of Scientific and Technological Information, Chinese Academy of Tropical Agricultural Sciences/Key Laboratory of Applied Research on Tropical Crop Information Technology of Hainan Province, Haikou 571101, China 2. Key Laboratory of Agricultural Remote Sensing, Ministry of Agriculture and Rural Affairs, Beijing 100081, China 3. Environment and Plant Protection Institute, Chinese Academy of Tropical Agricultural Sciences/Danzhou Hainan, Tropical Agro-Ecosystem, National Observation and Research Station, Haikou 571101, China
To analyze the phenological characteristics of the rubber forest in Hainan Island and to explore the phenological change characteristics of tropical forest vegetation, this study reconstructed the 2001—2015 MODIS NDVI time series using the Savitzky-Golay (S-G) filtering method based on the MODIS normalized difference vegetation index (NDVI) data. Then, this study extracted the phenological parameters of the rubber forest using the dynamic threshold method and typical sampling areas. Finally, this study analyzed the spatio-temporal changes in the phenological characteristics of the rubber forest. The results are as follows. During 2001—2015, the rubber forest started its foliation season mainly from mid-January to late March in spring and started its defoliation season from mid-November to late December in autumn, with the growing season lasting for about 7~10 months. On the time scale, the phenological characteristics did not significantly changed in the 15 years. Specially, the spring phenology occured about 0.94 days earlier, the autumn phenology showed an about 0.84 days delay, and the growing season was prolonged for about 1.79 days every year. On a spatial scale, the regions where the spring phenology occurred significantly earlier in the 15 years primarily included Baisha Li Autonomous County, Tunchang County, Qiongzhong Li-Miao Autonomous County, Wanning City, and Qionghai City, with a changing rate of -1.8~-0.1 d/a. The areas with a significant delay in autumn phenology included Danzhou City, Baisha Li Autonomous County, Tunchang County, Qiongzhong Li-Miao Autonomous County, Qionghai City, Wanning City, Ledong Li Autonomous County, Sanya City, and Baoting Li-Miao Autonomous County, with a changing rate of 0.5~2.7 d/a. The areas where the growing season was significantly prolonged mainly included Danzhou City and Baisha Li Autonomous County, with a changing rate of 0.2~0.8 d/a. The main characteristic of phenological changes of the rubber forest is the significant delay in the start date of the defoliation season.
胡盈盈, 戴声佩, 罗红霞, 李海亮, 李茂芬, 郑倩, 禹萱, 李宁. 2001—2015年海南岛橡胶林物候时空变化特征分析[J]. 自然资源遥感, 2022, 34(1): 210-217.
HU Yingying, DAI Shengpei, LUO Hongxia, LI Hailiang, LI Maofen, ZHENG Qian, YU Xuan, LI Ning. Spatio-temporal change characteristics of rubber forest phenology in Hainan Island during 2001—2015. Remote Sensing for Natural Resources, 2022, 34(1): 210-217.
Morisette J T, Richardson A D, Knapp A K, et al. Tracking the rhythm of the seasons in the face of global change:Phenological research in the 21st century[J]. Frontiers in Ecology and the Environment, 2009, 7(5):253-260.
doi: 10.1890/070217
Zhang S Q, Zhang B, Wang A H. A study on the relationship between distributive variation of wetlands and regional climate change in Sanjiang Plant[J]. Advance in Earth Sciences, 2001, 16(6):836-841.
Fan D Q, Zhao X S, Zhu W Q, et al. Revie od influencing factors of accuracy of plant phenology monitoring based on remote sensing data[J]. Progress in Geography, 2016, 35(3):304-319.
Lu P L, Yu Q, He Q T. Responses of plant phenology to climate change[J]. Acta Ecologica Sinica, 2006, 31(3):923-929.
[7]
Clerici N, Weissteniner C J, Gerard F. Exploring the use of MODIS NDVI-based phenology indicators for classifying forest general categories[J]. Remote Sensing, 2012, 4(12):1781-1803.
doi: 10.3390/rs4061781
[8]
Xin Q C, Broich M, Zhu P, et al. Modeling grassland spring onset across the Western United States using climate variables and MODIS-derived phenology metrics[J]. Remote Sensing of Environment, 2015, 161(5):63-77.
doi: 10.1016/j.rse.2015.02.003
[9]
Razak A, Shariff R, Ahmad N, et al. Mapping rubber trees based on phenological analysis of Landsat time series data-sets[J]. Geocarto International, 2018, 33(6):627-650.
[10]
Kou W L, Xiao X M, Dong J W, et al. Mapping deciduous rubber plantation areas and stand ages with PALSAR and Landsat images[J]. Remote Sensing, 2015, 7(1):1048-1073.
doi: 10.3390/rs70101048
[11]
Zhai D L, Yu H, Chen S C, et al. Responses of rubber leaf phenology to climatic variations in Southwest China[J]. International Journal of Biometeorology, 2019, 63(5):607-616.
doi: 10.1007/s00484-017-1448-4
pmid: 29130120
Chen H L, Chen X M, Chen Z L, et al. A primary study on rubber acreage estimation form MODIS:Based information in Hainan[J]. Chinese Journal of Tropical Crops, 2010, 31(7):1181-1185.
Chen X M, Chen H L, Li W G, et al. Remote sensing monitoring of spring phenophase of natural rubber forest in Hainan Province[J]. Chinese Journal of Agrometeorology, 2016, 37(1):111-116.
Tian G H, Li H L, Chen H L. Research on remote sensing extraction of planting information for rubber trees based on phenlogical characteristic parameters[J]. Chinese Agricultural Science Bulletin, 2013, 29(28):46-52.
[15]
唐海川, 何永东. 海南统计年鉴.行政区划(2018)[Z].2019.
Tang H C, He Y D. Hainan statistical yearbook.divisions of administrative areas(2018)[Z].2019.
Xu C G, Jiang J S, Shi L, et al. Investigation and evaluation on the ecological status of glue planting environment in China[M]. Beijing: China Agricultural Press, 2014:27-28.
[17]
张惜珠, 黄慧德. 橡胶树栽培与利用[M]. 北京: 金盾出版社, 2006:5-7.
Zhang X Z, Huang H D. Rubber tree cultivation and utilization[M]. Beijing: Jindun Press, 2006:5-7.
[18]
Chen B Q, Li X P, Xiao X M, et al. Mapping tropical forests and deciduous rubber plantations in Hainan Island,China by integrating PALSAR 25-m and multi-temporal Landsat image[J]. International Journal of Applied Earth Observation and Geoinformation, 2016, 50(5):117-130.
doi: 10.1016/j.jag.2016.03.011
[19]
Dong J W, Xiao X X, Chen B Q, et al. Mapping deciduous rubber plantations through integration of PALSAR and multi-temporal Landsat imagery[J]. Remote Sensing of Environment, 2013, 134(5):392-402.
doi: 10.1016/j.rse.2013.03.014
[20]
Chen J, Jönsson P, Tamura M, et al. A simple method for reconstructing a high-quality NDVI time-series data set based on the Savitzky-Golay filter[J]. Remote Sensing of Environment, 2004, 91(3) :332-334.
doi: 10.1016/j.rse.2004.03.014
[21]
Jönsson P, Eklundh L. Seasonality extraction by function fitting to time-series of satellite sensor data[J]. IEEE Transactions on Geo-science and Remote Sensing, 2002, 40(8):1824-1832.
doi: 10.1109/TGRS.2002.802519
[22]
Yin L C, Wang X F, Feng X M, et al. A comparison of SSEBop-model-based evapotranspiration with eight evapotranspiration products in the Yellow River basin,China[J]. Remote Sensing, 2020, 12(16):25-28.
doi: 10.3390/rs12010025
Xu J, Fan H D, Ni J. Meta-analysis of plant phenological change in China during 1950 and 2015[J]. Journal of Subtropical Resources and Environment, 2019, 14(2):1-11.
Yu Z, Sun P S, Liu S R. Phenological change of main vegetation types along a north-south transect of eastern China[J]. Chinese Journal of Plant Ecology, 2010, 34(3):316-329.
Ge Q S, Zheng J Y, Zhang X X, et al. Studies on climate and phenology changes in China in the past 40 years[J]. Progress in Natural Science, 2003, 13(10):1048-1053.
Zhong S Y, Zheng J Y, Ge Q S. Change of autumnal leaf coloring of woody plants in eastern China for the last 40 years[J]. Chinese Journal of Agrometeorology, 2010, 31(1):1-4.
[27]
Chen B Q, Xiao X M, Wu Z X, et al. Identifying establishment year and pre-conversion land cover of rubber plantations on Hainan Island,China using Landsat data during 1987—2015[J]. Remote Sensing, 2018, 10(8):13-19.
doi: 10.3390/rs10010013
